Indoor Power over Ethernet extender for extending compatible Axis network video installations beyond the standard 100 m Ethernet distance

The AXIS T8129 PoE Extender 5025-281 is an indoor Power over Ethernet extender designed to increase the cable distance between a PoE network source and compatible Axis network video equipment.

Standard Ethernet cabling is normally limited to 100 m (328 ft) between network devices. The T8129 can be installed inline with compatible Ethernet cabling to extend both network data and PoE power beyond this distance without requiring a separate local power supply at the extender.

It supports IEEE 802.3af and IEEE 802.3at, as well as compatible Axis High PoE applications. Actual achievable distance depends on factors including the connected device's power requirement, PoE source, cable specification and operating conditions.

Product Identification

Brand: Axis Communications
Product: AXIS T8129 PoE Extender
Part Number: 5025-281
Product Type: Power over Ethernet / Ethernet extender
Installation Environment: Indoor
Network Speed: 10/100 Mbps
PoE Standards: IEEE 802.3af / IEEE 802.3at
Connection: Shielded RJ45
Installation: Inline, plug-and-play
Additional Local Power Supply: Not required
Dimensions: 105 × 40 × 22 mm
Weight: 45 g

Axis lists 5025-281 for AU, BR, EU, IN, JP, UK and US regions.

Key Features

• Extends Ethernet and PoE beyond the conventional 100 m cable limit
• IEEE 802.3af compatible
• IEEE 802.3at compatible
• Axis High PoE 60 W compatible for supported configurations
• No additional power supply required at the extender
• Inline plug-and-play installation
• Two female Ethernet ports
• Automatic link speed configuration
• Automatic duplex configuration
• Automatic crossover configuration
• Maintains full-rate network throughput across the extended connection
• Compatible with Axis PoE network video products
• Compact 105 × 40 × 22 mm construction
• Wall or shelf mounting
• Designed for indoor installation

Extending Ethernet and PoE Beyond 100 m

The T8129 addresses a practical limitation of conventional copper Ethernet installations.

Instead of installing another powered network switch after the first 100 m, the extender can be connected inline between compatible cable segments. It receives power from the PoE source and forwards both Ethernet data and available PoE power toward the connected device.

Depending on the installation, additional T8129 units can be used at approximately 100 m intervals.

However, maximum distance is not the same for every camera or PoE source. Higher-power devices generally permit shorter extension distances than low-power devices.

Example Distance Scenarios

Axis provides examples demonstrating how power consumption affects maximum distance.

For a device requiring approximately 25 W, Axis gives an example of reaching approximately 200 m (656 ft) using one T8129 with an appropriate power source and cable configuration.

For a lower-power network device requiring approximately 5 W, Axis gives an example where the total connection may reach 400 m (1,312 ft) using three T8129 extenders at approximately 100 m intervals.

These are configuration examples rather than guaranteed distances for every installation.

Distance Depends on PoE Power Requirements

Axis categorizes extension capability according to device power demand.

Low-power devices: Longer total distances may be possible.

Medium-power devices: Maximum distance is reduced as power requirements increase.

Full-power PoE/PoE+ devices: Appropriate higher-power midspan and cable specifications may be necessary.

High PoE devices: Require compatible power-source configurations.

For this reason, the exact camera model and PoE source should be identified before selecting the number of extenders.

Network Specifications

Data Rate: 10/100 Mbps

Duplex: Half/full duplex

Ethernet Connectors: Shielded RJ45

Supported Wiring: EIA 568A / 568B

Recommended Network Cable: Shielded Category 5 or higher

Axis's current distance guidance generally references 24 AWG or heavier Cat 5e/Cat 6 cable, with some higher-power configurations requiring 23 AWG or heavier cable.

PoE Compatibility

The AXIS T8129 supports:

IEEE 802.3af

IEEE 802.3at

Compatible Axis High PoE 60 W configurations

The extender automatically forwards inline power toward the connected PoE device.

The available power at the far end nevertheless depends on the original PoE source, cable length, cable resistance, number of extenders and connected equipment.

Plug-and-Play Installation

The T8129 is designed to simplify installation.

No separate power adapter is required for the extender itself. The upstream PoE switch or midspan supplies the required inline power.

The two Ethernet ports automatically configure:

• Link speed
• Duplex
• Crossover

This reduces additional configuration requirements during installation.

LED Indicators

LED indicators are located at the RJ45 connector.

Power Indicator: Green when PoE is enabled

Network Indicator: Yellow for network link/activity

These indicators can help installers confirm power and Ethernet connectivity during setup.

Technical Specifications

Product: AXIS T8129 PoE Extender

Part Number: 5025-281

Data Rate: 10/100 Mbps

Duplex: Half/full duplex

Connectors: Shielded RJ45

Network Cabling: Shielded Category 5 or higher

PoE: IEEE 802.3af / IEEE 802.3at

Installation: Plug-and-play

Mounting: Wall or shelf

Environment: Indoor

Operating Temperature: -10°C to 50°C

Operating Humidity: Maximum 85% RH, non-condensing

Storage Temperature: -40°C to 74°C

Dimensions: 105 × 40 × 22 mm

Weight: 45 g

Compliance listed in supplied datasheet: IEEE 802.3af, IEEE 802.3at, RoHS, WEEE, CE

Dimensions and Weight

Length: 105 mm / 4.1 in

Width: 40 mm / 1.6 in

Height: 22 mm / 0.9 in

Weight: 45 g / 1.6 oz

Its compact dimensions allow the extender to be positioned inline without requiring another conventional network switch.

Applications

The AXIS T8129 may be considered for:

• Extended-distance IP camera installations
• CCTV networks exceeding 100 m copper Ethernet runs
• Warehouse surveillance
• Large retail environments
• Building surveillance
• Long corridors
• Parking facilities
• Industrial facilities
• Campus surveillance
• Large indoor premises
• Existing installations where adding local power is impractical

Actual suitability depends on cable route, device power consumption, network architecture and PoE source.

Purpose of Use

The primary purpose of the AXIS T8129 5025-281 is to extend both Ethernet communication and available PoE power beyond the normal 100 m copper Ethernet distance.

It can be useful where a compatible Axis network video device must be installed farther from the PoE switch or midspan and installing another powered network switch would be inconvenient.

Important: T8129 vs T8129-E

These are different products.

AXIS T8129 5025-281
Designed for indoor use.

AXIS T8129-E 01148-001
Outdoor-ready version with an IP66/IP67-rated enclosure.

Do not assume the standard T8129 has the outdoor environmental protection of the T8129-E.

This distinction is especially important for UAE installations exposed to outdoor heat, dust or moisture.

Things to Verify Before Ordering

Before ordering the AXIS T8129, confirm:

• Exact part number required
• Camera or other powered-device model
• Device PoE power requirement
• PoE switch or midspan model
• Total required cable distance
• Number of extenders required
• Cable category
• Cable conductor size
• Indoor or outdoor installation
• Required network throughput
• Environmental temperature
• Whether IEEE 802.3af, 802.3at or higher-power operation is required

For longer PoE runs, the complete power budget should be checked before installation rather than assuming a particular maximum distance.

Why NEOTECH® UAE

NEOTECH® focuses on accurate product identification and compatibility guidance before purchase.

For a PoE extender, choosing the correct product involves more than matching the connector. Camera power consumption, PoE source, cable type, cable distance and installation environment can all affect the achievable result.

Learn First. Decide Second. Buy Only If It Is Right for Your Needs.

There is absolutely no obligation or pressure to proceed with the purchase with us.

FAQ - AXIS T8129 5025-281

Q: What is the AXIS T8129 5025-281?
A: It is an indoor Ethernet and Power over Ethernet extender designed to extend compatible Axis PoE network-video installations beyond the conventional 100 m Ethernet distance.

Q: Does the AXIS T8129 require a separate power adapter?
A: No. Axis states that no additional power supply is required; power is supplied inline from the PoE switch or midspan.

Q: Does it support IEEE 802.3af?
A: Yes.

Q: Does it support IEEE 802.3at PoE+?
A: Yes. Axis lists compatibility with both IEEE 802.3af and IEEE 802.3at.

Q: Can the T8129 extend a connection to 200 m?
A: Potentially, yes, but maximum distance depends on the connected device, power source, cable and operating conditions. It should not be assumed that every device can operate at the same extended distance.

Q: Can multiple AXIS T8129 extenders be used?
A: Yes. Axis provides configurations using multiple extenders at approximately 100 m intervals, subject to the overall PoE power budget and supported distance.

Q: Is AXIS T8129 suitable for outdoor installation?
A: The standard T8129 is specified for indoor use. For outdoor installations, Axis offers the separate AXIS T8129-E Outdoor PoE Extender.

Q: What is the ordering part number for UAE/EU supply?
A: Axis currently lists 5025-281 for the EU region as well as AU, BR, IN, JP, UK and US.

Q: What warranty does Axis list for the T8129?
A: Axis's current product support page lists a 3-year warranty.
